Frequency Range：DC-4 GHz
Impedance：50 Ω
VSWR：≦1.4
Return Loss：≧15 dB
Withstand Voltage：500 Vrms
Insulation Resistance：1000 MΩ
Center Contact Resistance：8.0 mΩ
Out Contact Resistance：6.0 mΩ

Coupling Method：≧50 Cycles
Engagement Force：25 N. max.
Disengagement Force：2 N. min.
Housing Retention Force：110 N. min.

Temperature Range：-40°C - 105˚C
Vibration：ISO-20860-2 USCAR-2
Thermal Shock：ISO-20860-2 USCAR-2
Temperature/Humidity/Cycle：ISO-20860-2 USCAR-2
Mechanical Shock：ISO-20860-2 USCAR-2

Body/Metal Parts：Brass : Nickel
Insulators：PTFE
Female Center Contact：Be. Copper : Gold
Male Center Contact：Brass : Gold
Plastic Housing：PA-97, PBT

A：Radio Without Phantom supply
B：Radio With Phantom supply
C：GPS
D：GSM cellular phone
E：TV1/SDARS
F：TV2/SDARS
G：Remote Control Keyless Entry
H：GPS For Telematics and Navigation
I：Remote Control Parking Heating
K：Radio with IF
L：Not Defined
M：Not Defined
N：Not Defined
Z：Neutral Coding
